The OEM version of the GeForce GTX 560 Ti has different specifications than the retail model. The card is not based on the core GF114 but on a limited version of the GF110. Nvidia has disabled 5 of the 16 cluster architecture present full-GF110, leaving only 352 CUDA enabled Cores, and has used the MC bus of the GTX 570 with 320-bit address data.
The clock frequencies are set 732/1464/3800MHz (GPU / SPs / Mem). In summary, the GTX 560 OEM Ti is slightly less performance of the GTX 560 Ti "retail", while consuming more (vs 210W. 180W), but can handle a bandwidth GDDR5 VRAM and quantity of higher (1.25 or 2.5GB). The latter factor is counting on more of the promotional marketing OEM absolute performance.
Below is a table with specifications of the two cards: GTX 560 560 OEMGTX RetailGPUGF110GF114CUDA Cores352384Memory bus320-bit256-bitGPU clk.732 MHz822 MHzShaders clk.1464 MHz1644 MHzMem clk.3800 MHz4000 MHzBandwidth152 GB/s128 GB / smem buffer 1.25 - 2.5GB1 - 2 GBTDP210W170W
The clock frequencies are set 732/1464/3800MHz (GPU / SPs / Mem). In summary, the GTX 560 OEM Ti is slightly less performance of the GTX 560 Ti "retail", while consuming more (vs 210W. 180W), but can handle a bandwidth GDDR5 VRAM and quantity of higher (1.25 or 2.5GB). The latter factor is counting on more of the promotional marketing OEM absolute performance.
Below is a table with specifications of the two cards: GTX 560 560 OEMGTX RetailGPUGF110GF114CUDA Cores352384Memory bus320-bit256-bitGPU clk.732 MHz822 MHzShaders clk.1464 MHz1644 MHzMem clk.3800 MHz4000 MHzBandwidth152 GB/s128 GB / smem buffer 1.25 - 2.5GB1 - 2 GBTDP210W170W
